Step Three Phase Cycloconverter

DESCRIPTION:

This is a platform which is very useful for Students to understand the concept of Thyristor firing method & working of single phase cycloconverter on various load configurations. 2713 is provided with inbuilt AC/DC power supplies & exhaustive learning material.

Features:

• Built in Power Supply
• Easy to operate and understand
• On board firing circuits
• Gradual firing angle control up to 180°
• Test points to observe output of different blocks
• Sockets for making interconnections
• 2 Year Warranty

Scope of Learning:

• Study firing circuit of Three phase cycloconverter
• Study single phase mid- point cycloconverter with resistive and inductive load.

Technical Specifications:

1. On board firing circuits

• Ramp comparator firing scheme Interconnections 2mm sockets
• (Gold plated) Firing angle variation
• Gradual variation from 0 to 180 degree

2. SCR assembly

• 4 SCRs 2P4M, 400V/2A

3. Pulse transformer

• PT4503, 1:1:1

4. Mains Supply

• 220V/110V, 50 Hz /60 Hz

5. Load

• Resistance-279E, 5W Test points
• 9 nos (Gold plated) Learning material
• CD (Theory, procedure reference results, etc.), (Online optional)

6. Operating Conditions

• 0-40oC, 85% RH

Included Accessories :

• 2mm Patch cords (blue) 16”: 5nos.
• Mains cord : 1 no.
• Learning material (CD) : 1 no
